LC/UPC Connector Simplex Single-Mode 9/125μm Fiber Pigtail, 0.9mm PVC Jacket
Fiber pigtails provide a rapid method for connecting communication equipment. They are designed, manufactured, and tested in accordance with industry-standard protocols and performance requirements, meeting the most stringent mechanical and performance specifications.
Product Features:
●Tight-buffered coating with flame-retardant PVC fiber optic cable●G.657.A1 bend-insensitive fiber with minimum bend radius of 10mm
●Insertion loss and return loss compliant with optical testing standards
●Meets all performance requirements of IEC-61754 and TIA-604 (FOCIS)
●Supports splicing and mechanical termination in fiber optic cabling systems
Specification:
Connector A: LCConnector B: Bare Fiber
Fiber Type: 9/125 μm
Fiber Count: Simplex
Fiber Grade: G.657.A1
Minimum Bend Radius: 10 mm
Polish Type: UPC
Cable Outer Diameter: 0.9 mm
Cable Jacket: PVC
Jacket Color: Yellow
Wavelength: 1310 nm / 1550 nm
Durability: 1000 cycles
Insertion Loss: ≤0.3 dB
Interchangeability: ≤0.2 dB
Return Loss: ≥50 dB
Vibration Test: ≤0.2 dB
Operating Temperature: -40 to +75°C
Storage Temperature: -45 to +85°C
