LC/UPC Simplex Single-Mode 9/125μm Fiber Pigtail - 0.9mm PVC (OFNR)
Fiber pigtails provide a rapid method for field-terminating communication equipment. Designed, manufactured, and tested in accordance with industry-standard protocols and performance requirements, they meet the most stringent mechanical and performance specifications.
Product Features：
●Tight-buffered coating with flame-retardant PVC (OFNR) fiber optic cable●G.657.A1 bend-insensitive fiber with a minimum bend radius of 10mm
●Insertion loss and return loss compliant with optical testing standards
●Meets all performance requirements of IEC-61754 and TIA-604 (FOCIS)
●Supports splicing and mechanical termination in fiber optic cabling systems
Specification:
Connector A: LC
Connector B: Bare Fiber
Fiber Type: 9/125 μm
Fiber Count: Simplex
Fiber Grade: G.657.A1
Minimum Bend Radius: 10 mm
Polish Type: UPC
Cable Outer Diameter: 0.9 mm
Cable Jacket: PVC
Jacket Color: Yellow
Wavelength: 1310 nm / 1550 nm
Durability: 1000 cycles
Insertion Loss: ≤0.3 dB
Interchangeability: ≤0.2 dB
Return Loss: ≥50 dB
Vibration Test: ≤0.2 dB
Operating Temperature: -40 to +75°C
Storage Temperature: -45 to +85°C
