1x6 Blockless Fiber PLC Splitter, Single-Mode, 900μm Fiber, SC/APC Connector
A Planar Lightwave Circuit (PLC) splitter is an optical power management device fabricated using silica optical waveguide technology, designed to distribute optical signals from a Central Office (CO) to multiple end-user locations. Blockless PLC splitters provide superior fiber protection compared to bare fiber splitters, a result of the miniaturization of cassette-type splitters. They are primarily used in various connection distribution boxes or network cabinets.
Product Features:
●Evenly splits the input signal into 6 output ports●Low insertion loss ≤ 9.0 dB and low polarization-dependent loss ≤ 0.1 dB
●Fully passive optical branching device
●Wide operating wavelength range: 1260 ~ 1650 nm
●G.657A1 bend-insensitive fiber for low bending loss
●Commonly used in PON, data communications, LAN, CATV, LCP, FTTx, and other applications
Specification:
Packaging Type: Miniature
Configuration: 1x6
Fiber Type: G.657A1
Fiber Mode: Single-Mode
Connector Type: SC/APC
Splitting Ratio: 50/50
Fiber Diameter: 900μm
Pigtail Length: 1.5m
Insertion Loss: ≤9.0dB
Return Loss: ≥55dB
Uniformity: ≤0.55dB
Directivity: ≥55dB
Polarization Dependent Loss (PDL): ≤0.1dB
Temperature Dependent Loss (TDL): ≤0.5dB
Wavelength Dependent Loss (WDL): ≤0.3dB
Operating Wavelength: 1260-1650nm
Operating Temperature: -40 to +85°C
Storage Temperature: -40 to +85°C
Steel Tube Dimensions (H×W×D): 4×60×7mm
