Product Overview
The 10G SFP+ Direct Attach Copper (DAC) Cable is a high-performance, cost-effective solution for 10 Gigabit Ethernet (10GbE), Fibre Channel (8G/16G), and high-speed data center interconnects. With a 3-meter length, this passive twinaxial copper cable provides low-latency, plug-and-play connectivity between SFP+ ports, eliminating the need for separate transceivers.
Key Features
✔ 10Gbps High-Speed Transmission – Supports 10GbE, 8G/16G Fibre Channel, and InfiniBand SDR/DDR applications.
✔ Low Power & Passive Design – No signal processing required, reducing power consumption and heat generation.
✔ Hot-Pluggable & Tool-Free Installation – SFP+ MSA-compliant for seamless deployment without configuration.
✔ Low Latency & High Reliability – Copper-based transmission ensures stable performance in short-reach applications.
✔ Cost-Effective Alternative to Fiber – More affordable than optical transceivers while maintaining high signal integrity.
✔ Durable & Flexible – Twinaxial copper construction with EMI shielding for noise resistance.
✔ 3m Fixed Length – Optimized for rack-to-rack, switch-to-server, and storage networking.
Technical Specifications
●Data Rate: 10Gbps (10GbE, 8G/16G FC, InfiniBand)
●Connector Type: SFP+ to SFP+ (Male)
●Cable Type: Twinaxial Copper (Passive)
●Max Distance: 3m (ideal for short-reach connections)
●Operating Temperature: 0°C to 70°C (32°F to 158°F)
●Power Consumption: Passive (no additional power required)
●Protocols Supported:
10GBASE-CR (10G Ethernet)
Fibre Channel 8G/16G
InfiniBand SDR/DDR
Data Center & Storage Networking
Applications
●Data Center 10G Networking (switch-to-server, ToR, SAN)
●High-Frequency Trading (HFT) & Low-Latency Networks
●Cloud Computing & Virtualization
●Enterprise Storage (NAS/SAN)
●Telecom & Network Appliances
